Description
- Clock mode or wireless fish finder mode.
- No more long & heavy cable for transducer.
- Rechargeable: includes 3.7V rechargeable lithium batteries.
- 1.77inch TFT color LCD, pixels: 128V * 160H.
- User modes: language, sensitivity, depth range, zoom, depth alarm, fish alarm, fish icon, power save, depth units, temp. unit settings.
- 10-level sensitivity settings available. A higher-degree sensitivity can help you get more accurate information to detect the fish.
- Built in memory stores sonar setting when the fish finder is turned off.
- Two small holes on the wireless sensor allow you to tether with your fishing line and cast it onto water as far as you want.
- 60m / 200ft wireless operating range, 45m / 147ft depth capability.
- 90 degrees beam angle in 125Khz (Wireless).
- Display underwater contour and water temperature.
- Comes with fish depth scale and audible fish alarm.
- Small, medium, or big sized fish icon displays on the screen when fish is detected.
Specification:
1. Display: 1.77 inch TFT color LCD, pixels: 128V * 160H
Display Size: 50 * 38mm / 2.0 * 1.5in
User Mode: Wireless Mode / Clock Mode
Backlight: On/off White LED
Operating Frequency: 433.92MHz
Waterproof Design: Level-4 (Spray-water-proof)
Power: 3.7V rechargeable lithium batteries (included)
Power Source: DC 10-18V
Weight: 106g / 3.76oz
2. Sonar & Radio
Depth Capability: 0.6-45m / 2-150ft
Wireless Operating Range: 60m / 200ft
Sonar Coverage: 90 degrees beam angle in 125Khz
Operational Temperature: -14°F – 122°F (-10°C-50°C)
Power: 1 * replaceable CR2032 battery (included)
Size: 79 * 55 * 54cm / 3.1 * 2.2 * 2.1in
Weight: 44g / 1.55oz
Package List:
1 * Wireless Remote Sonar Sensor
1 * Watch Fish Finder
1 * USB Charging Cable
1 * USB AC Adapter Charger
1 * Vehicle Charger
1 * Manual
